RISC-Vのベクトル拡張命令RVVの環境を試す (1. gccのビルドとシミュレータのビルド)

f:id:msyksphinz:20190505224354p:plain

RISC-Vのベクトル拡張命令であるRISC-V Vector Extensionは仕様の策定されており、徐々に実装が進んでいる。

  • riscv-toolsのSpike命令セットシミュレータ
  • riscv-gnu-toolchainの対応

現在の実装の状況を見てみることにした。

riscv-toolsのインストール

riscv-toolsには、RVV(RISC-V Vector Extension)をサポートするためのブランチが切ってある。

git clone https://github.com/riscv/riscv-tools.git

新たにRVVのツールセットをインストールするディレクトリを決めて、インストールする。

  • riscv-isa-sim (Spike)
export RISCV=${HOME}/riscv_rvv
cd riscv-isa-sim
git checkout b1bde2b
./configure --prefix=${HOME}/riscv_rvv
make -j4
make install

バージョンの確認。

Spike RISC-V ISA Simulator 1.0.1-dev

usage: spike [host options] <target program> [target options]
Host Options:
  -p<n>                 Simulate <n> processors [default 1]
  -m<n>                 Provide <n> MiB of target memory [default 2048]
  -m<a:m,b:n,...>       Provide memory regions of size m and n bytes
                          at base addresses a and b (with 4 KiB alignment)
  -d                    Interactive debug mode
  -g                    Track histogram of PCs
  -l                    Generate a log of execution
  -h, --help            Print this help message
  -H                    Start halted, allowing a debugger to connect
  --isa=<name>          RISC-V ISA string [default RV64IMAFDC]
  --varch=<name>        RISC-V Vector uArch string [default v128:e32:s128]
  --pc=<address>        Override ELF entry point
  --hartids=<a,b,...>   Explicitly specify hartids, default is 0,1,...
  --ic=<S>:<W>:<B>      Instantiate a cache model with S sets,
  --dc=<S>:<W>:<B>        W ways, and B-byte blocks (with S and
  --l2=<S>:<W>:<B>        B both powers of 2).
...
git clone https://github.com/riscv/riscv-gnu-toolchain.git
cd riscv-gnu-toolchain
git checkout rvv-0.7.x
mkdir build
cd build
../configure --prefix=${RISCV}
make -j4

バージョン確認

$ riscv64-unknown-elf-gcc --version
riscv64-unknown-elf-gcc (GCC) 8.3.0
Copyright (C) 2018 Free Software Foundation, Inc.
This is free software; see the source for copying conditions.  There is NO
warranty; not even for MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.

簡単なプログラムをコンパイルしてみる。

まだauto-vectorizationは効かないようなので、サンプルでテスト用についているプログラムをコンパイルしてみる。

riscv64-unknown-elf-gcc -O3 -march=rv64gcv /home/msyksphinz/work/riscv/riscv-tools/riscv-gnu-toolchain/riscv-binutils/gas/testsuite/gas/riscv/vector-insns.s -c
riscv64-unknown-elf-objdump -d vector-insns.o | less
...
vector-insns.o:     file format elf64-littleriscv


Disassembly of section .text:

0000000000000000 <.text>:
       0:       80c5f557                vsetvl  a0,a1,a2
       4:       0005f557                vsetvli a0,a1,e8,m1,d1
       8:       7ff5f557                vsetvli a0,a1,2047
       c:       0455f557                vsetvli a0,a1,e16,m2,d4
      10:       12050207                vlb.v   v4,(a0)
      14:       12050207                vlb.v   v4,(a0)
      18:       10050207                vlb.v   v4,(a0),v0.t
      1c:       12055207                vlh.v   v4,(a0)
      20:       12055207                vlh.v   v4,(a0)

とりあえず、Vector命令をコンパイルできるツールセットを構築した。
